Adobe Illustrator Tutorial using pen Tool.
In this easy-to-follow beginner Adobe Illustrator Tutorial on adding texture we will be using the Simple process of inking using the Pen Tool, Cartoon brushes, Editing, and Live Paint.
Using Pen Tool
We will be using our 2 step approach to the pen tool. The first is using straight lines to just get down our anchor points. We will then be using the convert anchor tool to create curves and handles.
Flat Color & Shadows
We will be adding cast shadows using the knife tool to cut back into the flat color shapes we created using the Live Paint Bucket.
We will be adding some subtle textures along with some transparent gradients to our cartoon character.
Adding on Line Variation using Cartoon Brushes
You will have more control over the placement and width of each of your lines using the Cartoon Brushes (Download + Install). The process will be a combination of using the Brushes to get down the initial thickness and stroke width. The second step will be modifying the placement of the variation using so we can edit it later. This 2-Step Process allows for more control over your Line Variation compared to using your Tablet with Pressure.
1. The Direct Download will make it very easy to download the zipped brushes file. Simply Extract All of the contents and follow along with the rest of the video.
Open Other Library
2. In your Brushes Panel, Window - Brushes. In the Bottom Left Hand Corner you will see a Brushes Library icon that looks like books. Click on it and scroll down to Other Library. Open Brush Library from folder.
Adding Line Weight
3. Depending on your own Style or preference, I would recommend adding a little more line weight to your artwork. The mistake I see a lot of beginners make is keeping the line weight at 1pt.
4. We have 17 Brush Libraries in our folder. You can use any one of them during this tutorial. All you have to do is line up the thin edge which will be floating in space. The Thick ends will represent our values which will be merging into other areas and strokes.
Adobe Illustrator Brush Libraries include our 70 Cartoon, 100 Comic Strip, and 50 Vintage Mascot Brushes
Opening Color Swatches
Open the Swatch Window. On the bottom left hand corner you will see the Open Swatch Libraries icon. At the bottom of the drop-down menu you will see Open Other Library. Go to our resource folder in the Color Palettes folder to Open ASE files. The ASE files have been created to make your life easier while going through the Challenge Series. Once you open the Library- click on the folder icon next to the swatches to move them from the library to the swatches.
Coloring with Fills
One of the easiest and fastest ways of filling in your color is through using Fills. The main thing to look for is enclosed shaped. We have done nothing but build with Shapes so coloring is super easy. Keep this in mind as you are going through the other tutorials where we don't have any shapes.
Select each color using the Magic Wand Tool (Adjust to Tolerance 5) each color. Add on a Radial Gradient to the frosting layers (3). Use the lightest and Darkest Color Swatch from the color set of 3. Adjust the slider to control where the values hit. Troubleshooting: Double check your fill is in front and not your stroke.
You can use the Gradient Tool to gain some control over where the gradient hits on your shapes. The tool will control the same features that are in the panel. I use the tool when I don't want to guess and check angle degrees or aspect ratio percentages.
How to Color in Adobe Illustrator
One of the easiest and fastest ways of filling in your color is through Live Paint. Live Paint Bucket is a part of the Shape Builder Tools which builds the shapes in the exact shape you need it. Select All. Go up to Object - Live Paint - Make. If you have a grayed out Make it simply means you didn't have anything selected. I do recommend Deselecting by clicking on your artboard before clicking on a Color Swatch. *Remember Everything is still Selected so it will Color the Full Selection if you click on a Color Swatch with everything selected. Click on the Live Paint Bucket (K) and Click to Dump Color. It will feel like the Paint Bucket in Adobe Photoshop.
